Gemsy GEM1900A - Page 148

序号
NO.
图号 REF NO.
名称
DESCRIPTION
数量
AMT
注解
NOTE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
1
(2)
(1)
(1)
(1)
(1)
(1)
(2)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(2)
(1)
(1)
(1)
(2)
(2)
(1)
(1)
1
1
1
2
1
1
1
1
1
1
2
Pick-up device compl.
Screw 11/64-40 l=7
Lever spring hook
Button support lever spring
Pick-up foot installing base
Pick-up installing base
Installing shaft
E-ring 7
Slide block
Presser plate
Button support release lever
Screw 11/64-40 l=7
Button support lever shaft
Screw 11/64-40 l=7
Button clamp base
Screw
Washer 4.8x11.5x2
Button clamp base
Screw 9/64-40 l=4.6
Thrust collar d=6.35 w=8
Screw 11/64-40 l=3.5
Button support lever
Button support rubber asm.
Button support rubber
Shank button holding clamp
Screw 11/64-40 l=7
Feed plate
Feed plate, a
Screw 11/64-40 l=4.3
Screw 11/64-40 l=9.5
Washer 4.8x11.5x2
Washer 5x10.5x1
Support plate
Stationing block shaft
Snap ring,for connecting rod
Nut 15/64-28
Screw 11/64-40 l=4
Screw 3/16-32 l=13.5
Button clamp support,front
Button clamp support,rear
Needle bar
Wiper asm.
Moving plate link a
Screw 9/64-40 l=6
Button support link
Hinge screw d=6.35 h=3.2
Needle hole guide
Needle tqx3 #14
Bushing
Connecting link
Bolt
509- 22-01
501- 07-54
509- 22-03
509- 22-04
509- 22-05
509- 22-06
509- 22-07
508- 07-50
509- 18-02
509- 22-10
509- 22-11
508- 07-57
509- 22-13
508- 07-57
509- 22-15
509- 22-16
509- 22-17
509- 22-18
509- 22-19
509- 22-20
509- 22-21
509- 22-22
509- 22-23
509- 22-24
509- 22-25
508- 07-57
509- 22-27
509- 22-28
508- 07-57
509- 22-30
509- 22-31
501- 07-45
509- 22-33
509- 22-34
509- 22-35
509- 22-36
509- 22-37
509- 22-38
509- 22-39
509- 22-40
509- 22-41
509- 22-42
509- 22-43
509- 22-44
509- 22-45
509- 22-46
509- 22-47
509- 22-48
509- 22-49
509- 22-50
509- 22-51
138
22.选购件 Option Components(2) for 1903A
