SC201(1900A/1903A) Memory Switch (Service Class)
41
38.0
Presser don’t lift and
depress pedal to sewing
0:usual
1:Presser don’t lift
0
43. 1
Speed Choice When
Trimming
0:400rpm
1:800rpm
1
Speed of moving knife
spreading the thread; the
trimming is performed after
the machine stops.
44. 1
Feeding Cloth When
Trimming at the
Direction of Easy
Trimming
0:No
1:Yes
1
45. 16
Diameter of Thread
Guider when Feeding at
the time of Trimming
16-40
(1.6mm-4.0mm)
16
(1.6mm)
Amount of feeding will be
more if the value is set larger
47. 0
Prohibit Trimming
0:Normal
1:Prohibited
0
Prohibit all trimming
operation.
52.--
Conduction Time of
Wiper Solenoid
10-500ms
50
Valid only wiper solenoid is
chosen.
53.--
Release Time of Wiper
Solenoid
10-500ms
100
Valid only wiper solenoid is
chosen.
56.--
+X Direction(R)Shifting
Range
-20-20mm
20
Not consider the shape of
Presser when delivered.
57.--
-X Direction(L)Shifting
Range
-20-20mm
-20
Not consider the shape of
Presser when delivered.
58.--
+Y Direction(B)Shifting
Range
-20-10mm
10
Not consider the shape of
Presser when delivered.
59.--
-Y Direction(F)Shifting
Range
-20-10mm
-20
Not consider the shape of
Presser when delivered.
62. 0
Perform READY when
Power ON
0:Normal
1:Perform READY
when Power on
0
67.--
Main Control Software
Version
0 或 1
1
Refer to 【3.3 Restore
Default Setting】
68.--
Stop Position
Compensation
-10-+10
0
150.0
Set the Safety Switch to
be Invalid
0:Normal
1:Invalid
0
241.0
Machine type
0:reinforcement
7:Lockstitch Button
0
Refer to chapter 4.1
The functions above assumes for special repair or maintenance.
3.3 Restore Default Setting
When the users change the settings by accident, or the control system fails to work, you
could try to restore the default setting.
