使用说明书 Operation Instruction
2.存储器开关的设定例 Example of the memory switch setting
(1).缝制速度上限的设定 Setting the max. sewing speed limitation
设定例：把缝制速度的上限设定到1800rpm。
1）在缝制LED灭灯的状态按 键。存储器被启动，
存储器开关NO.1的内容。
缝纫机的最高速度限制用存储器NO.1设定，所以不需
要变更，但是可以变换用 键、 键显示的存储
器开关NO.1。
2）存储器开关NO.1被显示的状态下，按 键，点亮
缝制LED。存储器开关NO.1的内容(缝纫机的最高速度
限制值)被显示。
3）用 键、 键设定为“1800”。
4）按 键登记。缝制LED灭灯。
5）按 键，返回通常状态。
（注意）在通常状态，缝纫机速度不能设定到该值以
上。
M
M
Setting example : Setting the max. sewing speed limitation to
1,800 rpm
1) Press key in the state that the sewing LED is put out.
The memory switch is started and the contents of memory
switch No. 1 are indicated.
It is not necessary to change the sewing speed since the max.
speed limitation of the sewing machine is set with memory
switch No.1. The indicated memory switch No. can be changed
over with or key.
2) Press key in the state that memory switch No. 1 is
indicated to make the sewing LED light up. The contents of
memory switch No, 1 (max.sewing speed limitation value of
the sewing machine) are indicated.
3) Set "1800" with or key.
4) Register the value with key. Sewing LED goes off.
5) Press key to return to the normal state.
(NOTE) The sewing machine speed in the normal state cannot
be increased more than the value which has been set here.
M
M
39
