使用说明书 Operation Instruction
(2).光卷绕底线时 To wind a bobbin independently
1）按 键，让缝制LED灭灯。
2）用 键,选择卷线 。
（注意）如果缝制LED亮灯时不能选择。
3）按 键，压脚下降，缝制LED亮灯。
4）踩踏踏板之后，缝纫机开始转动。
5）再次踩踏板，或者按 键、 键之后缝纫机停止
转动。
6）按 键之后，缝纫LED灭灯，压脚所上升， 键
变为有效。
（注意）刚刚打开(NO)电源后，卷线不动作。请设定
1次图案NO.等，按 键让缝制LED亮灯之后再进行操
作。
1) Press key to make the SEWING LED go off.
2) Select the bobbin winder with key.
(NOTE) Selection cannot be performed when the Sewing LED
is lit up.
3) Press key. The work clamp feet come down and the
Sewing LED lights up.
4) When the pedal switch is depressed, the sewing machine
rotates.
5) When the pedal is depressed again, or key or key is
pressed, the sewing machine stops.
6) When key is pressed, the Sewing LED goes off, the
work clamp feel go up and key becomes effective.
(NOTE) Bobbin winder does not work immediately after turning
ON the power. Perform the bobbin winding after setting pattern
No. or the like once, pressing the key, and making the
sewing LED light up.
21
