SC201(1900A/1903A) General Instruction
1
1. General Instruction
1.1 Specifications of SC201
No.
SC201
1
Purpose
Bartacking / Button Lockstitch
2
Sewing Area
X(lateral) direction 40mm × Y(longitudinal) direction 30mm
3
MAX. Sewing
Speed
3000rpm（when sewing pitches are less than 4.5mm in
X-direction and 3.5mm Y-direction）
4
Stitch Length
0.1mm – 10.0mm (adjustable in 0.1mm step )
5
Feed Motion of
Work Clamp Foot
Intermittent Feed(2-draft drive by stepping motor)
6
Needle Bar Stroke
41.2mm
7
Needle
DP×5，DP×17
8
Type of driving
Work Clamp Foot
Driven by pulse stepping motor
9
Lift of Work Clamp
Foot
13mm (Standard), Max. 17mm
10
Total Number of
Standard Patterns
50
11
Wiper Type
To work together with Work Clamp Foot driven by Stepping Motor
12
Thread Clamp
Standard : 0
13
Needle Thread
Tension
Electrical Thread Tension Release
14
Shuttle
Standard Semi-rotary Hook（oil wick lubrication）
15
Lubricating Method
Rotary Part：Lubricate with minimum amount
16
Lubricating Oil
(Liquid)
Ordinary Sewing Machine Lubricating Oil (Liquid)
17
Grease
Ordinary Sewing Machine Grease
18
Data Recording
Flash Memory
19
Enlarging/Reducing
Facility
20%~200%(1% step) in X direction and Y direction respectively
20
Enlarging/Reducing
Method
By increasing/decreasing the stitch length
21
Max. Sewing Speed
Limitation
400-3000rpm (100rpm step)
22
Pattern Selection
Specifying Pattern No. Type(1-200)
23
Bobbin Thread
Counter
Up/Down Type (0 – 9999)
24
Sewing Machine
Motor
500W Compact AC Servomotor (Direct Drive)
TYPE
ITEM
