使用说明书 Operation Instruction
11
11.马达护罩的安装 Installing the motor cover
把马达护罩①用附属的螺丝安装到缝纫机主机上。
1) 在放倒缝纫机的状态，连接电线，如图所示用线
束夹①捆绑。
2) 如图所示，让电线稍稍弯垂，用电线固定板②固
定电线。
（注意）放倒缝纫机时，请确认机头支杆安装在机台
上。
Install motor cover ① on the machine main unit with screws
supplied with the machina as accessories.
1) In the state that the sewing machine is tilted, connect the
cords, and bundle them with clip band ① as shown in the
figure.
2) Fix the cords with cords setting plate ② in the state that
the cords slacken as shown in the figure.
(NOTE) When you tilt the sewing machine, make sure that
the sewing machine head support bar Is placed on the table.
①
12.电线的处理 Managing the cord
悬垂
slack
①
To Next Page
