Gemsy GEM1900A - Page 72

Feed plate blank
Work clamp foot face plate (asm.)
Presser blank
Needle hole guide
Finger guard (1)
Name of Parts Type Part No. Remarks
Without knurl/processed
With knurl/processed
Without knurl/stainless steel
With knurl/Processed (right)
With knurl/Processed (Left)
A=1.6 B=2.6 With relief slit
A=1.6 B=2.0 Without relief
slit
A=2.3 B=4.0 Without relief
slit
A=2.7 B=3.7 Without relief
slit
A=56.5 B=64
A=59 B=74
A=66.5 B=43
A=21.5 B=35.5
14120109
14120307
14120505
14121263
14121701
14121800
B2426280000
D2426282C00
14109607
D2426MMCK00
13533104
13548300
13573407
14120000
T=0.8
Face plate for presser
blank
Standard type
F and M types
For heavy-weight material
For extra heavyweight
material
For large size
bartacking
For lengthwise
bartacking
For specially ordered
work clamp
