Gemsy GEM1900A - Page 94

序号
NO.
图号 REF NO.
名称
DESCRIPTION
数量
AMT
注解
NOTE
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
501-01-47
530-01-26
501-01-48
134-02-01
25-06000000-09
24-04000000-08
12-40400625-01
21-04308090-02
12-80500512-01
12-80400612-01
508-01-79
12-40400825-02
508-01-57
508-01-57P
508-01-58P
508-01-57-03
508-01-67-04
橡皮塞D= 14.7 L= 7
橡皮塞D= 15.5 L= 9
橡皮塞D= 21 L=9
绕线器组 件
卡簧C6
卡簧E4
轴承挡圈
锁扣簧
拉簧
绕线器座
调节板
绕线轴
绕线器凸 轮轴
绕线杆
螺钉M4X 6
垫圈φ4. 5Xφ10X0 .8
基座销
轴承
绕线轴架
梭心垫圈
绕线器凸 轮
螺钉M5X 5
绕线轮
绕线轮固 定螺钉M4X 8
扭簧
橡皮圈
曲柄轴底 盖
螺钉M4X 8
机壳组件
车壳（机 头）
底座
拼装螺钉
拼装销
Rubber Plug D=14.7 L=7
Rubber Plug D=15.5 L=9
Rubber Plug D=21 L=9
Bobbin Winder Unit
Retaining Ring
E-ring 4
Btw Bearing Spacer
Bobbin Spring
Btw Spring
Btw Base
Btw Cam Plate
Btw Shaft
Btw Lever Shaft
Btw Lever
Screw M4x6
Washer 4.5x10x0.8
Btw Base Shaft
Btw Bearing
Btw Shaft Base
Btw Spacer
Btw Cam Lever
Screw M5 L=5
Btw Wheel
Screw M4 L=8
Btw Torsion Spring
Btw Wheel Rubber
Crank Rod Under Cover
Screw M4x8
1
2
3
1
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(2)
(1)
(1)
(1)
(1)
(1)
(2)
(1)
(1)
1
3
1
1
1
3
2
84
1.头部、外装部件 Frame & Miscellaneous Cover Components
