UCM6200 Series User Manual
General Settings
Call Progress Tones
Configure call progress tones including ring tone, dial tone, second dial tone,
message waiting tone, ring back tone, call waiting tone, busy tone and reorder
tone using the following syntax:
f1=val, f2=val[, c=on1/ off1[- on2/ off2[- on3/ off3]]];
 Frequencies are in Hz and cadence on and off are in 10ms).
 “on” is the period (in ms) of ringing while “off” is the period of silence. Up to
three cadences are supported.
 Please refer to user manual of the SIP devices to be provisioned for more
details
HEADSET Key Mode
Select “Default Mode” or “Toggle Headset/Speaker” for the Headset key.
Please refer to user manual of the SIP devices to be provisioned for more
details.
Table 28: Global Policy Parameters->Contact List
LDAP Phonebook
Source
Select "Manual" or "PBX" as the LDAP configuration source.
 If "Manual" is selected, the LDAP configuration below will be applied to the
SIP end device.
 If "PBX" is selected, the LDAP configuration built-in from UCM6200 web
UI->Settings->LDAP Server will be applied.
Address
Configure the IP address or DNS name of the LDAP server.
Port
Configure the LDAP server port. The default value is 389.
Base DN
This is the location in the directory where the search is requested to begin.
Example:
 dc=grandstream, dc=com
 ou=Boston, dc=grandstream, dc=com
User Name
Configure the bind "Username" for querying LDAP servers. The field can be
left blank if the LDAP server allows anonymous binds.
Password
Configure the bind "Password" for querying LDAP servers. The field can be left
blank if the LDAP server allows anonymous binds.
Number Filter
Configure the filter used for number lookups. Please refer to user manual for
more details.
Name Filter
Configure the filter used for name lookups. Please refer to user manual for
more details.
Version
Select the protocol version for the phone to send the bind requests. The default
value is 3.
Name Attribute
Specify the "name" attributes of each record which are returned in the LDAP
