Grandstream Networks UCM6200 - Table 7: Operation Log Column Header; Figure 19: Operation Logs

P a g e | 46
UCM6200 Series User Manual
Figure 19: Operation Logs
The operation log can be sorted and filtered for easy access. Click on the header of each column to sort. For
example, clicking on "Date" will sort the logs according to operation date and time. Clicking on "Date" again will
reverse the order.
Table 7: Operation Log Column Header
Date
The date and time when the operation is executed.
User Name
The username of the user who performed the operation.
IP Address
The IP address from which the operation is made.
Results
The result of the operation.
Page Operation
The page where the operation is made. For example, login, logout, delete user, create
trunk and etc.
Specific Operation
Click on to view the options and values configured by this operation.
User could also filter the operation logs by time condition, IP address and/or username. Configure these
conditions and then click on .
