Status
Display extension number (including feature code). The color indicator has the
following definitions.
 Green: Free
 Blue: Ringing
 Yellow: In Use
 Grey: Unavailable
Extension
Display the extension number.
Name/Label
First name and last name of the extension.
Message
Display message status for the extension.
Example: 2/4/1
Description: There are 2 urgent messages, 4 messages in total and 1 message
that has been already read.
Type
Displays extension type.
 SIP User
 IAX User
 Analog User
 Ring Groups
 Voicemail Groups
Other operations are also available in extension status section:
 Click on "Extensions", the web page will redirect to extension configuration page which can also be
accessed via web GUI->PBX->Basic/Call Routes->Extensions.
 Click on to refresh the extension status.
 Click on one of the tabs to display
the corresponding extensions accordingly.
 Click on [ + ] to expand the status detail table.
 Click on [ - ] to hide the status detail table.
Queues
Users could see all the configured call queue status in this section. The following figure shows the call queue
6500 being in used.
