P a g e | 332
UCM6200 Series User Manual
or SD Card.
Capture Filter
Enter the filter to obtain the specific types of traffic, such as (host,
src, dst, net, proto…).
Start
Click to start the trace.
Stop
Click to stop the trace.
Download
Click to download the trace if trace is stored locally.
The output result is in .pcap format. Therefore, users could specify the capture filter as used in general network
traffic capture tool (host, src, dst, net, protocol, port, port range) before starting capturing the trace.
IP Ping
Enter the target host in host name or IP address. Then press "Start" button. The output result will dynamically
display in the window below.
Figure 243: Ping
Traceroute
Enter the target host in host name or IP address. Then press "Start" button. The output result will dynamically
display in the window below.
