P a g e | 144
UCM6200 Series User Manual
PCMA, GSM, AAL2-G.726-32, G.722, G.729, G.723, iLBC, ADPCM, LPC10, H.264,
H.263, H.263p and VP8.
Search and Edit Extension
All the UCM6200 extensions are listed under Web GUI->PBX->Basic/Call Routes->Extensions, with status,
Extension, CallerID Name, Technology (SIP, IAX and FXS), IP and Port. Each extension has a checkbox for
users to "Modify Selected Extensions" or "Delete Selected Extensions". Also, options "Edit” , "Reboot"
and "Delete" are available per extension. User can search an extension by specifying the extension number
to find an extension quickly.
Figure 95: Manage Extensions
 Status
Users can see the following icon for each extension to indicate the SIP status.
Green: Free
Blue: Ringing
Yellow: In Use
Grey: Unavailable (the extension is not registered or disabled on the PBX)
 Edit single extension
Click on to start editing the extension parameters.
 Reboot the user
Click on to send NOTIFY reboot event to the device which has an UCM6200 extension already
registered. To successfully reboot the user, "Zero Config" needs to be enabled on the UCM6200 web GUI-
>PBX->Zero Config->Auto Provisioning Settings.
