UCM6200 Series User Manual
EXTENSION GROUPS
The UCM6200 extension group feature allows users to assign and categorize extensions in different groups to
better manage the configurations on the UCM6200. For example, when configuring "Enable Filter on Source
Caller ID", users could select a group instead of each person's extension to assign. This feature simplifies the
configuration process and helps manage and categorize the extensions for business environment.
Configure Extension Groups
Extension group can be configured via Web GUI->PBX->Call Features->Extension Groups.
 Click on "Create New Extension Group" to create a new extension group.
 Click on to edit the extension group.
Select extensions from the list on the left side to the right side.
Figure 144: Edit Extension Group
 Click on to delete the extension group.
Using Extension Groups
