UCM6200 Series User Manual
FXS/FXO waiting.
FXS/FXO busy.
FXS/FXO not configured.
FXS/FXO disconnected.
Other operations are also available in interface status section:
 Click on "Interfaces Status", the web page will redirect to ports configuration page which can also be
accessed via web GUI->PBX->Internal Options->Ports Config.
 Click on to refresh the interface status.
 Click on [ + ] to expand the interface details.
 Click on [ - ] to hide the interface details.
Parking Lot
The UCM6200 supports call park using feature code. When there is call being parked, this section will display
the parking lot status.
Figure 208: Parking Lot Status
Table 110: Parking Lot Status
Caller ID
Display the caller ID who parks the call.
Channel
Display channel for the call park.
Extension
Display the parking lot number where the call is parked/retrieved.
Timeout
Display timeout (in seconds) for the parked call. The status page will
dynamically update this timer from 120 seconds (default) to 0. When the timer
reaches 0, the caller who parks the call will be called back.
Other operations are also available in parking lot status section:
 Click on "Parking Lot", the web page will redirect to feature codes page which can also be accessed via
web GUI->PBX->Internal Options->Feature Codes.
 Click on to refresh the parking lot status.
