GRAPHTEC FC8000-75 - Page 100

FC8000-UM-251-9370 8-6
8. TROUBLESHOOTING
Error
code
Error Display Cause Verication item Solution
E01018
E01018 HARDWARE
Y POSITION ALARM
POWER OFF THEN ON
Cutting
conditionsdonot
suitthecutting
medium.
Cuttingconditions. Lowerthecutting
SPEEDand/orthe
cuttingFORCE.
Movementofthe
pencarriageis
beingobstructed.
Isthereanything
blockingtheYslider?
Turnofftheplotter,
removetheobstacle,
thenturntheplotterback
on.
Excessiveload
iscausingthe
currenttothe
motortoexceed
theratedvalue.
(1) DoestheYslider
movesmoothly?
No.....Checkandadjust
theYbelttension
andYmotorbelt
tension.
Yes....Verifyitem(2).
(2) IstheYexible
cablesecurely
connected?
 OrIstheYexible
cablebroken?
No.....Connectit
securely.
Yes....ReplacetheY
exiblecableif
defective.
Homesensor
orsensorplate
adjustment.
(3) IstheYhome
sensorplateposition
correct?
No.....Checkandadjust
theX-home
sensorposition.
Yes....Replacethe
X-homesensorif
defective
(4) IstheYhome
sensorposition
correct?
No.....Checkandadjust
theX-home
sensorposition.
Yes....Replacethe
X-homesensorif
defective.
Motor (5) DoestheX-motor
turnsmoothly?
No.....Replacethe
X-motorif
defective.
Yes....Replacethemain
boardifdefective.
E01019
E01019 HARDWARE
XY POSITION ALARM
POWER OFF THEN ON
Loadonthe
motorwastoo
large.
Isthereanything
blockingtheXorY
movement?
Turnofftheplotter,
removetheobstacle,
thenturntheplotterback
on.
