FC8000-UM-251-9370 8-12
8. TROUBLESHOOTING
Error
code
Error Display Cause Solution
E04013
E04013 ARMS
MARK SCAN ERROR!
NOT ENOUGH LENGTH
IN +Y DIRECTION
Ithasexceededdetectionarea
whiledetectingtheregistration
mark.
Checkthemedia.
Checktheprintpositionofthe
registrationmark.
E04014
E04014 ARMS
MARK SCAN ERROR!
EXCEED CUTTING
AREA DURING
+Y DETECTION
Ithasexceededdetectionarea
whiledetectingtheregistration
mark.
Checkthemedia.
Checktheprintpositionofthe
registrationmark.
E04015
E04015 ARMS
MARK SCAN ERROR!
NOT ENOUGH LENGTH
IN -Y DIRECTION
Ithasexceededdetectionarea
whiledetectingtheregistration
mark.
Checkthemedia.
Checktheprintpositionofthe
registrationmark.
E04016
E04016 ARMS
MARK SCAN ERROR!
EXCEED CUTTING
AREA DURING
-Y DETECTION
Ithasexceededdetectionarea
whiledetectingtheregistration
mark.
Checkthemedia.
Checktheprintpositionofthe
registrationmark.
E04017
E04017 ARMS
MARK SCAN ERROR!
MOVING DESTINATION
IS OUT OF AREA
Ithasexceededdetectionarea
whiledetectingtheregistration
mark.
Checkthemedia.
Checktheprintpositionofthe
registrationmark.
E04018
E04018 ARMS
MARK SCAN ERROR!
MEDIA SET LEVER IS
LOWERD
JOB IS CANCELD
Mediasetleverwaslowered. Reloadthemediaandtry
again.
E04019
E04019 ARMS
CANCEL IS SELECTED
AT MOVE DISTANCE
Therewascanceloperationbythe
user.
E04020
E04020 ARMS
MARK SCAN ERROR!
DETECTION ERROR
JOB IS CANCELED
Thereisadefectinthedetection
settingsvalue.
Checkthesettingsvalue.
E04021
E04021 ARMS
MARK SCAN ERROR!
MARK IS NOT FOUND
IN EFFECTIVE AREA
Registrationmarkwasnot
detectedintheautodetection
area.
Checkthemedia.Checkthe
printpositionoftheregistration
mark.
E04022
E04022 ARMS
JOB IS CANCELED
Therewascanceloperationbythe
user.
E04023
E04023 ARMS
MARK SCAN ERROR!
MARK WAS NOT FOUND
Registrationmarkwasnot
detected.
Readjustthesensorlevel.
Changethecolorofthe
registrationmark.
Checkthemedia.
Checktheprintpositionofthe
registrationmark.
