GRAPHTEC FC8000-75 - Page 14

FC8000-UM-251-9370 2-4
2. PARTS NAMES and FUNCTIONS
Assembly
(1) Assembletheleftandrightstandsides.Fastenabaseassemblytoeachofthestandsidebarswithfour
socketheadcapscrewsusingtheAllenwrench.
Socket head
cap screw
Stand side bar
Base
assembly
Stand side bar
(2) Looselyfastenthecenterbartotheleftandrightstandsideswithfoursocketheadcapscrews(twoon
eachside),usingtheAllenwrench.
Center bar
Stand sides
Socket head
cap screw
Socket head
cap screw
(3) Attachamediastockertoeachoftheleftandrightstandsideswithtwosocketheadcapscrews,using
theAllenwrench.Mountthemediastockerssothateachoneprotrudesdirectlyabovethelongerofthe
twobaseassemblylengths.
Media stocker
Media stocker
Socket head cap screw
Base assembly
Stand sides
Short
Long
