FC8000-UM-251-9370 2-7
2. PARTS NAMES and FUNCTIONS
(2) Insert2baskettubes(short)intothemountfromthesidewithoutthecap.Assemble2setsasshown
below.
Cap
Mount
Basket tube (short)
(3) Connectthebaskettubes(short)tothejointsinsertedonthebaskettubes(long)attheendofthebasket
attachedinstep1.
 Mountingpositionofthecenterbasketpipe(long)dependsontheloadingdirection.
Basket tube (long)
Cloth basket
Joint
For front
loading
For rear
loading
(4) Fixthepartassembledin3tothestandusingthesocketheadcapscrews.Assemblyiscompletedby
separatingbaskettofrontandbackofthecenterbar.
Socket head
cap screw
Socke thead
cap screw
Center bar
Stand
