2. PARTS NAMES and FUNCTIONS
Attaching a Pen to the Two-Pen Holder (Option)
Thetwo-penholderisafactory-installedoption,andcannotberetrotted.
(1) Loosenthepenholderscrew.
(2) Whilepushingthepenholderintheupwarddirection,pushthepenallthewayintotheholderuntilits
angecontactstheupperpartoftheholder.
•Whenyoupushthepenholderwithyourngers,thebladetipmaybeprotruding.
Takecarenottocutyourngers.
Flange
Upper part of pen holder
(3) Makesurethatthepenbracketisengagedonthepen’sange,andthentightenthescrew.
Bracket to hold pen
Flange
