2. PARTS NAMES and FUNCTIONS
Attaching a Plotting Pen to the Pen Station
(1) Openthepen-holdmechanismonthepenstation,andthenattachapen.
(2) Makesurethatthebracketofthepenstationisengagedintheuppergrooveofthepen.
(3) Closethepen-holdmechanismonthepenstationtoholdthepeninplace.
•Donotleaveapenattachedtothepenstationforalongperiodoftime,asthe
pentipwilldryupandmakeitunusable.
•Tostorethepen,removeitfromthepenstationandreplaceitsprotectivecap.
