GW Instek GSP-9300 User Manual

GSP-9300 User Manual
98
Move Delta Marker(s)Manually
Move Delta or
Reference Marker
1. Press
Marker
> Delta[F4]> MoveRef[F2] to move
the reference marker.
2. Press
Marker
> Delta[F4]> MoveDelta[F3] to move
the Delta marker.
3. Move the selected marker in the same fashion
as a normal marker, see page 96
Move Both
reference and
delta marker
1. Press either Move Pair Span[F4] or Move Pair
Center[F5] to move both markers at the same
time.
Move Pair Span:
Sets the frequency span
between both markers.
The span can be positive
or negative:
1
+span
Δ1
Δ1
-span
1
Move Pair Center:
Moves both markers at
the same time, keeping
the span between both
markers even
throughout.
2. Move both markers in the same fashion as a
normal marker, see page 96
