GSP-9300 User Manual
220
Limit Line Testing
The limit line is used to set the upper or lower amplitude limits
over the entire frequency range. The limit lines can be used to
detect whether the input signal is above, below or within the limit
lines.
The limit lines can be manually or automatically created. The limit
lines can be manually edited by frequency or from the trace data or
marker points.
 Creating a Limit (Point by Point) → from page 220.
 Creating a Limit (from Trace Data) → from page 222.
 Creating a Limit (from marker data) → from page 223.
 Creating a Limit (from marker data) → from page 223
 Delete Limit Line → from page 224
 Pass Fail Testing → from page 225
Creating a Limit (Point by Point)
Create a limit manually, point by point. A
maximum of ten points can be used.
> Edit Select Limit[F1]>Limit Line
[F1] and choose a limit line.
2. Press Point by Point[F2].
The GSP-9300 is split into two screens. The top
screen shows the trace and limit lines and the
bottom screen shows the limit line table.
