GSP-9300 User Manual
94
Marker
A Marker shows the frequency and amplitude of a waveform point.
The GSP-9300 can activate up to 6 markers or marker pairs
simultaneously as well as up to 10 peak markers in the marker table.
The marker table helps editing and viewing multiple markers in a
single display.
A delta marker shows the frequency and amplitude difference from
a reference marker.
The GSP-9300 can automatically move a marker to various
locations including the peak signal, center frequency, and
start/stop frequency. Other marker operations regarding signal
peaks are available in the Peak Search function.
 Activating a Marker → from page 95
 Move Marker Manually → from page 96
 Move Marker to Preset Locations → from page 96
 Activate Delta Marker → from page 97
 Move Delta Marker(s)Manually → from page 98
 Marker Functions → from page 99
 Move Marker to Trace → from page 101
 Show Markers in Table → from page 102
 Peak Search → from page 103
 Peak Configuration → from page 105
 Peak Table → from page 106
