GW Instek GSP-9300 User Manual

GSP-9300 User Manual
158
2FSK Pass Fail Testing
Description
The Limit Edit function puts a pass limit on the
frequency deviation and carrier power and a
high/low limit on the amplitude of each peak.
Measurement
Range
Freq. Deviation:
1Hz ~ 400kHz
Carr. Offset:
1Hz ~ 400kHz
High Limit:
-120dBm ~ 30dBm
Low Limit:
-120dBm ~ 30dBm
Operation:
configuration
1. Press
Measure
> 2FSK[F3]>Limit Edit[F5] and set
the limits.
Freq. Deviation[F1]
If the measured
deviation is above this
limit, it will be judged as
Fail.
Carr. Offset[F2]
If the measured carrier
offset is above this limit,
it will be judged as Fail.
High Limit[F3]
If the amplitude for one
of the peaks is above the
high limit, it will be
judged as Fail.
Low Limit[F4]
If the amplitude for one
of the peaks is below the
low limit, it will be
judged as Fail.
2. Press Pass/Fail[F6] and turn Pass/Fail on.
