GW Instek GSP-9300 - Move Marker Manually; Move Marker to Preset Locations

GSP-9300 User Manual
96
Move Marker Manually
Operation
1. Press
Marker
> Select Marker[F1] and select a
marker number.
2. Use the left/right arrow keys to
move the marker one grid division.
3. Use the scroll wheel to move the
marker in fine increments.
4. Alternatively, the numeric keypad
in combination with the F1~ F7
keys can be used to directly enter
the frequency of the marker
position.
7 8 9
654
1 2 3
/0
Move Marker to Preset Locations
Description
The
Marker
key is used to move the selected
marker to a number of preset positions.
Functions
Mkr>Center:
Mkr>Start:
Mkr>Stop:
Mkr>CF Step:
Mkr>Ref Lvl:
Move to center frequency.
Move to start frequency.
Move to stop frequency.
Move to step frequency.
Move to reference level
amplitude.
Note
When the
Marker
key is used, the span and other
settings may be automatically changed.
