GW Instek GSP-9300 User Manual

GSP-9300 User Manual
54
Example:
Ref: 0dBm
Before reference level offset(offset: 0dB)
Ref: 10dBm
Reference level
offset: 10dB
After reference level offset (offset: 10dB)
Amplitude Correction
Description
Amplitude correction adjusts the frequency
response of the spectrum analyzer by altering
the amplitudes at specified frequencies. This
allows the spectrum analyzer to compensate for
loss or gain from an external network or device
at certain frequencies.
Range
Correction Sets:
5 sets of 30 points
Amplitude:
-40dB to +40dB
Amplitude Resolution:
0.1dB
Frequency:
9kHz to 3GHz
Frequency Resolution:
1Hz
