BASIC OPERATION
103
Peak Search
Move Marker to Peak
The
Peak
Search
key is used to find trace peaks.
1. Press
Marker
> Select Marker[F1] and select a
marker number.
2. Press
Peak
Search
>Peak Search[F1]. The marker will
move to the highest signal peak.
3. To continually search for the peak on each
sweep, press,
Peak
Search
>More [F7]>Peak Track[F1]
and set Peak Track to on.
Move Marker and Peak to Center
The Center function moves the marker to the
highest signal peak and moves the center
frequency to that peak. This function can be
used with the Next Peak, Next Peak Right, Next
Peak Left and Min Search peak functions, see the
Search for Peaks section on page 104 for details.
1. Press
Marker
> Select Marker[F1] and select a
marker number.
2. Press
Peak
Search
>Mkr>Center[F2].
Note
The span will not be changed.
