GW Instek GSP-9300 User Manual

REMOTE CONTROL
275
Configure RS232C
Background
The RS232C interface is used for remote control
with a PC.
RS232C
Configuration
settings
Baud Rate
Stop bit: 1 (fixed)
Parity: none (fixed)
Data bit: 8 (fixed)
Connection
Connect an RS232C cable from
the PC to the rear panel RS232
port.
1. Press
System
>More[F7]>RmtInterface
Config[F1]>RS232 BaudRate[F4] to set the baud
rate.
300
600
1200
2400
4800
9600
19200
38400
57600
115200
RS232C Remote Control Function Check
Functionality
check
Invoke a terminal application such as Realterm.
To check the COM port No, see the Device
Manager in the PC. For WinXP; Control panel
→ System → Hardware tab.
Run this query command via the terminal after
the instrument has been configured for RS232
remote control (page 275).
*idn?
This should return the Manufacturer, Model
