GW Instek GSP-9300 - Attenuation

BASIC OPERATION
49
Attenuation
Description
The attenuation of the input signal level can be
set to automatic (Auto) or manual (Man). When
the attenuation is set to Man, the input
attenuator can be changed manually in 1dB
steps.
Operation
1. Press
Amplitude
> Attenuation[F2] and select Auto
or Man.
2. If Man was selected, enter the attenuation level
and unit.
Range:
Units:
Resolution:
0dBm ~ 50dBm
dBm
1dB
Display
Attenuation level
