ADVANCED OPERATION
225
Pass Fail Testing
Description
Before pass/fail testing can begin, limit lines for
the upper and lower limits must first be saved.
See page 220, 222 & 223 to save limit lines.
Operation
1. Press
Limit
Line
>Pass/Fail Test.
2. To set a high limit, press High Limit[F1] and
choose one of the limit lines as the upper (high)
limit.
3. To set the low limit, press Low Limit[F2] and
select one of the limit lines as the lower limit.
4. Press Pass Criterion[F3] and select the pass
criteria.
Criteria:
All-In, Max-In, Min-In
5. Press Pass/Fail Mode[F5] to select what the GSP-
9300 will do on a fail judgment. Single will stop
testing after a single fail. Continue will continue
testing after each fail judgment.
Pass/Fail Mode:
Single, Continue
6. Press Pass/Fail Test[F4] and turn the testing on.
7. The test result appears in the bottom of the
display, and the high and low limit lines (if
enabled) appear on the display.
Pass:
, with green grid border.
Fail:
, with red grid border.
