GW Instek GSP-9300 User Manual

BASIC OPERATION
101
Move Marker to Trace
Description
The Marker Trace function moves the selected
marker to any of the currently active traces.
Operation
1. Press
Marker
> Select Marker[F1] and select a
marker number.
2. Press [F2] to turn the selected marker on.
3. Press More[F7]>Marker Trace[F1] and choose a
trace to move the current marker to. Only active
traces can be selected.
Auto[F1]
Trace1[F2]
Trace2[F3]
Trace3[F4]
Trace4[F5]
4. In the example below, marker 1 is set to Trace1
and marker 2 is set to Trace2.
Marker 1, Trace 1
Marker 2, Trace 2
