GW Instek GSP-9300 User Manual

GSP-9300 User Manual
144
ASK Measurement
Description
The ASK function can be used to analyze ASK
signals. It can either display the demodulated
waveform or the symbols encoded in the signal.
Manchester or Miller line codes can also be
decoded.
Measurement
items
AM Depth:
Current, Min, Max
Mod. Rate:
Current, Min, Max
Carrier Pwr:
Current, Min, Max
Carrier Freq Offset:
Current, Min, Max
SINAD:
Current, Min, Max
Operation:
configuration
1. Set the center frequency to the carrier frequency
(page 41).
2. Press
Measure
> Demod[F2]>ASK[F4]>ASK
Analysis[F1] and turn ASK Analysis on.
 Any other measurement mode will automatically be
disabled.
3. The display splits into two screens. The top
shows the ASK waveform in the wave view
(time domain waveform) or the symbol view.
The bottom screen shows the ASK
measurements.
