GW Instek GSP-9300 User Manual

ADVANCED OPERATION
157
3. The display splits into two screens. The top
shows the trace with peak markers for the first
and second FSK frequencies (carrier and hop
frequency). The bottom screen shows the 2FSK
measurement results in real time.
2FSK measurement
Peak 1, Peak 2
4. To set the peak threshold line, press Peak
Threshold:
Threshold range:
-120dBm ~ 30.0 dBm
5. To set max hold limit, press Max Hold:
Max Hold range:
-130dBm ~ 30.0 dBm
Note
For more information about Peak Threshold and
Max Hold parameters, please see the Trace chapter
on page 81.
