GSP-9300 User Manual
56
2. Press Edit[F3].
The GSP-9300 will split into two screens. The
top screen will show the waveform and the
bottom screen will provide an overview of the
correction points.
Spectrum display
Correction points
Frequency of
selected point
3. Press Point Num[F1] and choose a point number
to edit. Point numbers can only be created in
order. For example Point Num 2 can only be
selected after Point Num 1 is created, and point
Num 3 can only be selected after Point Num 2
is created and so on.
4. Press Frequency[F2] and choose the frequency of
the selected point.
5. Press Gain Offset[F3] and choose the amplitude
of the selected point. The units will be the same
as those used for the vertical scale.
