GW Instek GSP-9300 User Manual

GSP-9300 User Manual
90
Parameters
Video Edge:
Determines the polarity of the
video trigger.
Positive: The signal voltage
exceeds the video level at the
trigger frequency.
Negative: The signal voltage is
lower than the video level at
the trigger frequency.
Video Level:
The trigger voltage level.
Trigger
Frequency:
Sets the frequency to start
triggering
Operation
1. Press
Trigger
>Trigger Condition[F2]>Video[F1]
2. Press Video Edge[F1] and choose the edge.
Range:
Positive, Negative
3. Press Video Level[F2] and set the video voltage
trigger level.
Trigger level:
(-120dBm to +30dBm)
+Ref Level Offset
4. Press Trigger Freq[F3] and choose the frequency
at which the spectrum analyzer will check the
triggering conditions.
Frequency:
0-3GHz+frequency offset
Display Icon
The Video Level trigger icon is displayed
when the Video trigger is activated.
