Haas VF Series Service Manual

96-8100 1-15-96
104
MECHANICAL SERVICE
HAAS AUTOMATION, INC.
SERVICE MANUAL
VF-SERIES
6. Tag both limit switch connections for reassembly, then unplug the limit switches' and the power's connections at
the carriage casting.
7. Remove the four SHCS attaching the turret motor and mounting plate to the tool carriage casting.
Fig. 12-6 Carriage casting with cover removed.
8. Carefully lift the turret motor assembly off of the tool carriage casting.
NOTE: The gear motor should never be disassembled and is not field-serviceable. All gear motors should be returned
to Haas for evaluation and rebuilding.
INSTALLATION -
1. Grease the locking element and drive pin on the Geneva driver. Also, grease the teeth on the Geneva star on the ATC.
2. Rotate the Geneva driver until the cam depresses the limit switch on the turret motor assembly.
3. Place a narrow strip of paper around the locking element of the Geneva driver and install the turret motor assembly
onto the casting. Be certain that the locking element of the Geneva driver is seated against the star with the paper strip

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
