1-15-96 96-8100
175
TABLE OF CONTENTS
TECHNICAL REFERENCE
SERVICE
MANUAL
VF-SERIES
DISCRETE INPUTS
# Name Description # Name Description
1 TC IN Tool Changer In 17 SP LOK Spindle Locked
2 TC OUT Tool Changer Out 18 SP FLT Spindle Drive Fault
3 T ONE At Tool One 19 SP ST* Spindle Not Stopped
4 LO CNT Low Coolant 20 SP AT* Spindle Not At Speed
5 TC MRK T.C. Geneva Mark 21 LO OIL Spindle/GB coolant low
6 SP HIG Spindle In High 22 spare
7 SP LOW Spindle In Low 23 spare
8 EM STP Emergency Stop 24 spare
9 DOOR S Door Open Switch 25 UNCLA* Remote tool unclamp
10 M-FIN* Not M Func Finish 26 LO PH A Low voltage in phase 1
11 OVERV* Not Over Voltage 27 spare
12 LO AIR Low Air Pressure 28 spare
13 LO LUB Low Lube Oil 29 GR FLT Ground fault
14 OVRHT* Not Over Heat 30 SKIP Skip Signal
15 DB OPN Tool Unclamped 31 SPIGOT
16 DB CLS Tool Clamped 32 CNVEYR
DISCRETE OUTPUTS
# Name Description # Name Description
1 SRV PO Servo Power On 17 SPGCW Spigot clockwise
2 SP FOR Spindle Forward 18 SPGCCW Spigot counter/clockwise
3 SP REV Spindle Reverse 19 Spare
4 SP RST Spindle Reset 20 Spare
5 4TH BK 4th Axis Brk Rel 21 PRE-CH Pre-charge
6 COOLNT Coolant Pump 22 HTC SH Horizontal T.C. shuttle
7 AUT OF Auto Turn Off 23 5TH BK 5th Axis Brake
8 SP FAN Spind Motor Fan 24 Y160 Door Lock
9 TC IN Tool Changer In 25 M21
10 TC OUT Tool Changer Out 26 M22
11 TC CW Tool Changer CW 27 M23
12 TC CCW Tool Changer CCW 28 M24
13 SP HIG Spindle High Gear 29 GRNBCN Red beacon worklight
14 SP LOW Spindle Low Gear 30 RDBCN Red beacon worklight
15 T UNCL Tool Unclamped 31 CNVENA Conveyor Enabled
16 SP LOK Spindle Lock Cmd 32 CNVREV Conveyor reverse
The 38 inputs are numbered the same as the 38 connections on the inputs printed circuit board. The last eight outputs
are reserved for expansion by HAAS.
The second page of diagnostic data is displayed using the PAGE UP and PAGE DOWN keys. It contains:
