Haas VF Series Service Manual

96-8100 1-15-96
198
ELECTRICAL SERVICE
SERVICE MANUAL
VF-SERIES
LUBRICATION CHART
FOR THE VF-SERIES MILL
LOCATION Under the control panel at the rear of Above the spindle head Side of machine
the machine
DESCRIPTION Piston pump with 30-minute cycle time.
Pump is only on when spindle is turning
or when axis is moving.
LUBRICATES Linear guides and ball nuts Transmission only
QUANTITY 1-QT. Tank 2-QT. Tank 40 gallons
LUBRICANT Mobil Vactra #2 Mobil DTE 25 Water soluble,
synthetic

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
