Haas VF Series Service Manual

1-15-96 96-8100
HAAS AUTOMATION, INC.
61
MECHANICAL SERVICE
SERVICE MANUAL
VF-SERIES
9. Check the switch several times. This is done by by moving the piston up and down to ensure that the "Tool Unclmp"
status appears when the piston makes contact with the shim and drawbar, and does not appear (DB OPN=0, DB
CLS=1) when it is in the retracted position.
Fig. 5-5 Push piston down to hold shim in place.

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
