4. Unscrew the assembly from the T-fitting.
Fig. 1-5 Top view of spindle lube/air solenoid assembly.
5. Replace the assembly, ensuring it is approximately horizontal to the floor, and tighten fittings securely.
6. Reconnect all air lines.
7. Reconnect wiring leads at the quick-disconnect in the wiring channel. Slide cover back into place.
8. Restore air supply to the machine.

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
