Haas VF Series Service Manual

1-15-96 96-8100
135
TABLE OF CONTENTS
ELECTRICAL SERVICE
VF-SERIES
SERVICE MANUAL
HA AS AUTOMATION, INC.
2. Turn the main switch (upper right of electrical cabinet) to the off position.
3. Using a large flat tip screwdriver, loosen the three screws on the cabinet door and then open the door enough
to safely work on the electrical panel.
4. Disconnect all leads to the Power Distribution (POWER) board and move aside for removal. Ensure all cables are
properly labeled for reconnecting later. The illustration on the following page shows all cable numbers and the
locations on the POWER board.
5. After all cables have been disconnected, remove the seven screws holding the POWER board to the cabinet and
remove the board. Take care to hold the POWER board in place until all screws have been removed.
NOTE: If you need to replace the LOW VOLTAGE POWER SUPPLY board, please skip the next step.
6. Replace the POWER board, attaching it with the seven screws previously removed. Don't forget to use the lower left
screw for a ground connection.
7. Reconnect all cables to the POWER board at their proper location (refer to Fig. 4-7).

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
