Haas VF Series

1-15-96 96-8100
163
TABLE OF CONTENTS
TECHNICAL REFERENCE
SERVICE MANUAL
VF-SERIES
P7 Y encoder input (670)
P8 Z encoder input (680)
P9 A encoder input (690)
P30 B encoder input (690B)
P31 C encoder input (690C)
P18 Jog encoder input (750)
P20 Spindle encoder input (1000)
P10 Inputs from I/O board (550)
P11 I/O relays K1-8 (510)
P12 I/O relays K9-16 (520)
P13 I/O relays K17-24 (530)
P14 I/O relays K25-32 (540)
P15 Low Voltage Power (860)
P16 Spindle command output (720)
P19 Address bus
P24 Axis home switches (990)
