Haas VF Series Service Manual

96-8100 1-15-96
206
CABLE LOCATIONS
HAAS AUTOMATION, INC.
SERVICE MANUAL
VF-SERIES
980 / P9
970 / P12
1060 / P13
110 / P11
860A / P5
80 / P8
920 / P10
FAN / P7
570 / P1
580 / P2
590 / P3
600 / P4
R11R15R2 FU2
FU1
NE2
NE1
LE1
FU3
NE3
TB2
TB1
93W
92V
910
-
+
-
+
-
+
-
+
REGEN
X DRIVER
LOW VOLTAGE
Y DRIVER
LOW VOLTAGE
Z DRIVER
LOW VOLTAGE
A DRIVER
LOW VOLTAGE
DRIVERS 160VDC
160VDC
115VAC / T1
SERVO POWER
VOLTAGE MON.
OV V
GND FAULT
12VDC
RESISTORS
FAN
SERVO DISTRIBUTION PCB 32-5020

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
