96-8100 1-15-96

212

CABLE LOCATIONS

HAAS AUTOMATION, INC.

SERVICE

MANUAL

VF-SERIES

ADDRESS BUSS P4 DATA BUSS P5

760 / P13

700 / P3

KEYBOARD

INFO

VIDEO

LOW VOLTAGE

RS422

P14

P15

FLOPPY DRIVE

FLOPPY POWER

SPARE

P11

P10

P12

VIDEO & KEYBOARD PCB 32-3201
