Haas VF Series Service Manual

96-8100 1-15-96
214
CABLE LOCATIONS
HAAS AUTOMATION, INC.
SERVICE MANUAL
VF-SERIES
P21 / 980 P22 / 730B
ADDRESS BUSS P19 DATA BUSS P1
550 / P10
750 / P18
660 / P6
670 / P7
680 / P8
690 / P9
860 / P15
610 / P2
620 / P3
630 / P4
640 / P5
540 / P14
530 / P13
520 / P12
510 / P11
LOW VOLTAGE
X DRIVE
SIGNAL
Y DRIVE
SIGNAL
Z DRIVE
SIGNAL
A DRIVE
SIGNAL
720 / P16 SP SPEED CMD
I/O RELAYS
K25-32
I/O RELAYS
K17-24
I/O RELAYS
K9-16
I/O RELAYS
K1-8
SP DRIVE LOAD
VOLTAGE MON. 0-5V
MOTIF INPUTS /
I/O OUTPUTS
JOG INFO
X ENCODER OUTPUT
Y ENCODER OUTPUT
Z ENCODER OUTPUT
A ENCODER OUTPUT
P24 / 990
HOME SENSORS
D1
+5V
D2
HALT
B DRIVE
SIGNAL
640B
1000 / P20
SP ENCODER OUTPUT
B ENCODER OUTPUT 690B
MOCON PCB 32-4023 C
