Haas VF Series Service Manual

1-15-96 96-8100
HAAS AUTOMATION, INC.
39
TABLE OF CONTENTS
ALARMS
SERVICE MANUAL
VF-SERIES
510 Illegal Operator or See Macros section for valid operators.
Function Use
511 Unbalanced Right Number of right brackets not equal to the number of left brackets.
Brackets
512 Illegal Assignment Use Attempted to write to a read-only macro variable.
513 Var. Ref. Not Allowed Alphabetic addresses N and O cannot be combined with macro variables.
With N Or O Do not declare N#1, etc.
514 Illegal Macro Address A macro variable was used incorrectly with an alpha address. Same as
Reference 513.
515 Too Many Conditionals Only one conditional expression is allowed in any WHILE or IF-THEN
In a Block block.
516 Illegal Conditional A conditional expression was found outside of an IF-THEN, WHILE,
Or No Then or M99 block.
517 Exprsn. Not Allowed A macro expression cannot be concatenated to N or O. Do not declare
With N Or O O[#1], etc.
518 Illegal Macro Exprsn An alpha address with expression, such as A[#1+#2], evaluated
Reference incorrectly. Same as 517.
519 Term Expected In the evaluation of a macro expression an operand was expected and not found.
520 Operator Expected In the evaluation of a macro expression an operator was expected and not found.
521 Illegal Functional An illegal value was passed to a function, such as SQRT[ or ASIN[.
Parameter
522 Illegal Assignment A variable was referenced for writing. The variable referenced is read
Var Or Value only.
523 Conditional Reqd THEN was encountered and a conditional statement was not processed
Prior To THEN in the same block.
524 END Found With No An END was encountered without encountering a previous matching
Matching DO DO. DO-END numbers must agree.
525 Var. Ref. Illegal Variable cannot be read during axis movement.
During Movement
526 Command Found On A G-code command was found on a WHILE-DO or END macro block.
DO/END Line Move the G-code to a separate block.
527 = Not Expected Or Only one Assignment is allowed per block, or a THEN statement is missing.
THEN Required

Haas VF Series Specifications

General

Machine Type	Vertical Machining Center
Control	Haas CNC Control
Z-Axis Travel	20-30 inches (varies by model)
Y-Axis Travel	16 - 30 inches (varies by model)
Spindle Motor	20-30 hp (depending on model)
Tool Capacity	20-40 tools (varies by model)
