Hillstone SG-6000 X-Series User Manual

LED Color/Status Description
INLINE Green/Always on The Bypass module is working in the inline mode.
Orange/Always on The Bypass module is working in the bypass mode.
Off The bypass module is not powered and it is in the
bypass mode.
Notes: LED indicators on different expansion modules vary. Please refer to the
actual expansion module.
Power Supply Module
SG-6000-X7180 supports the AC power module and DC power module. You can power the
device by installing AC or DC power modules as needed and then connecting them to the cor-
responding external power supply.
Four power modules can be installed in the power expansion slots located on the back panel of
SG-6000-X7180. In addition, power modules are hot-swappable.
Table 2-45 Table: Parameters of the SG-6000-X7180 Power Module
Power Module
Type
Input Voltage Range
of the External
Power Supply
Maximum Output
Power of the AC
Power Module
Number of Power Modules
Required for Normal Device
Running
AC Power Module 100 ~ 240V AC 850W At least 2
100 ~ 240V AC
240V DC
650W At least 2
Note: If every expansion slot
is installed with an expansion
module, please install at least 3
AC power modules. If you
92
