3. Remove the seal label applied to the SD slot.
4. Push the SD card slightly and it will pop out.
Notes: Hillstone recommends 16GB and 32GB Kingston or SanDisk SD cards. To
ensure the storage writing speed, the SD card should have a speed of at least Class
4.
Cooling System
The cooling system of SG-6000-X7180 consists of two fan trays. The fan trays are horizontally
located in FAN0 (on the front panel) and FAN1 (on the back panel).
Each fan tray of SG-6000-X7180 has 6 fans and one air filter.
Figure 2-58
Fig: Fan Tray of SG-6000-X7180
The air inlet is at the left side of the front panel. Air is pushed from the air inlet and then goes
through the chassis cage. The air is exhausted out of the air outlet which is at the right side of the
front panel.
Figure 2-59
Fig: Air Flow Through the Chassis of SG-6000-X7180
96
