Attribute Description
Negotiation
Mode
In the 40GE working mode 1*40Gbps
In the 4*10GE working mode 4*10Gbps
Notes:
l Make sure you use Hillstone transceiver modules for the optical ports on Hill-
stone devices.
l To avoid dust falling into the QSFP+ socket, you should place a rubber dust
cap (originally in the accessory box) over the QSFP+ port.
40GE(QSFP+) Transceiver Module
To connect devices via the 40GE(QSFP+) transceiver modules, use the optical fiber with the
LC-type connector. SG-6000 X series supports three Hilltone 40GE(QSFP+) transceiver mod-
ules: TRAN-SR-QSFP+, TRAN-LR-QSFP+, and TRAN-QSFP+-SWDM4. All transceiver mod-
ules are hot-swappable.
Table 2-58
Table: Specifications of the QSFP+ Transceiver Module
Model TRAN-SR-QSFP+ TRAN-LR-QSFP+
TRAN-QSFP+-
SWDM4
Form Factors QSFP+ QSFP+ QSFP+
Interface Spe-
cification
40GBase-SR4 40GBase-LR4 40GBase-SWDM4
IEEE Standard IEEE 802.3ba IEEE 802.3ba IEEE 802.3ba
Dara Rate 40Gbps 40Gbps 40Gbps
Connector Type MPO LC LC
Preface 111
